Categories
> Card type: EM or EM+HID Card
> Capacity: 10,000 card users
> Waterproof IP68
> Rainproof, moistureproof, durable
> Can be used as WG26 reader
Brand:
S4AItem NO.:
M2Standalone Access Controller
Model No.: M2 EM, EM+HID
Product Description
> Waterproof IP68
> Rainproof, moistureproof, durable
> Capacity: 10,000 card users
> Can be used as WG26 reader
> Can connect external EM/HID WG26 output reader Two units can be interlocked
> Can realize Anti-passback function for single or two doors
> Can add consecutive user cards
> Can set master add card/master delete card
|
Card type |
EM, EM&HID |
|
Waterproof |
IP68 |
|
Environment Humidity |
10%～90% |
|
Lock output |
≤3A |
|
Working voltage |
DC12V±10％ |
|
Static electricity |
≤30mA |
|
Alarm output |
≤20A |
|
Output short circuit protection time |
≤100μS |
|
Card read distance |
5～8cm |
|
Ambient temperature |
-45℃～60℃ |
|
Door Opening Time |
0～99s(Adjustable) |
|
Dimension |
115*56*22mm |
|
Standalone Access Controller and Reader Without Keypad |
|||
|
Model No. |
Quantity/Carton |
Gross Weight |
Carton Size |
|
M2EM |
54pcs |
24.2KG |
55.5x39.9x40cm |
|
M2EH |
54pcs |
24.2KG |
|
|
M2MF |
54pcs |
24.2KG |
|
S4A User Manual M2_Standalone Access Controller and Reader Without Keypad
> Card Type: MF or MF Card > Waterproof degree: IP65 > Capacity: 15,000 users > Working frequency: 125KHz or 13.56MHz
> Card type: EM or EM+HID Card > Can be used as WG26 reader > Can connect external EM/HID WG26 output, reader > Two units can be interlocked > Can realize Anti-passback function for single or two doors > Can add consecutive user cards > Can set master to add card/master delete card
> Card Type: EM or MF Card > Working frequency: 125KHz, 13.56MHz > 10,000 card users > Operating voltage: DC12~24V > Wiegand 26/34 Input and Output > Support admin add card, admin delete card and setting card
> Card type: EM or MF Card > User Capacity: 10,000 card users > Voltage: DC12~24V
>Card Type: 125KHz EM Card >User Capacity: 10,000 card users >Keypad Characteristic:Operate by infrared remote control
> Card type: EM Card > User Capacity: 10,000 card > Operate by infrared remote control > Support admin add card, admin delete card and setting card
>Operating Voltage:DC 12-24V >Operating Humidity:0%~95% >Door Relay Time:0～99s(adjustable)
>Operating Voltage:DC 12-24V >Operating Humidity:0%~95% >Door Relay Time:0～99s(adjustable)
S4A appreciate any of your inquiries and sincerelyhope to enjoy a fruitful long-term business relationship with youto share in the mutual benefits, If you have any questions, please feel free to contact us.
