UHF RFID USB Desktop Reader Only with Keyboard Emulation Output

> 860~868MHz, 902~928MHz frequency band(frequency customization optional)

> Built-in antenna with effect distance up to 200mm*

> Support USB2.0 interface with VSP(Virtual Serial Port) or HID mode

  • Brand:

    S4A
  • Item NO.:

    UHF-05
  • Specifications
  • Wiring Diagram
  • Package
  • Download

UHF RFID USB Desktop Reader Only with Keyboard Emulation Output

Model No.: UHF-05 Black


Description:

UHF-05 is a high performance UHF RFID desktop Reader. It is designed upon fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, attendance system, anti-counterfeit and industrial production process control system.



Features:

> Self-intellectual property

> Support ISO18000-6C(EPC C1G2) , ISO18000-6B protocol tag

> 860~868MHz, 902~928MHz frequency band(frequency customization optional)

> FHSS or Fix Frequency transmission

> RF output power up to 13dbm(adjustable)

> No external power source needed

> Built-in antenna with effect distance up to 200mm*

> Support USB2.0 interface with VSP(Virtual Serial Port) or HID mode

> Slim outline

> Provide SDK and demo software to facilitate further development

* Effective distance depends on protocol, tag and environmen

UHF RFID USB Desktop Reader

UHF RFID USB Desktop Reader

UHF RFID USB Desktop Reader

S4A Datesheet_UHF RFID USB Desktop Reader Only With Keyboard Emulation Output
