>Operating Voltage:10- 16V (typ. 12V/1A)
>Operating temperature:-40°C~85°C
>Average power consumption:< 2.5W
Brand:
S4AItem NO.:
ITS-AX279G millimeter wave radar detection systems
Model No.: ITS-AX2
Features
1.Bluetooth mode mobile phone APP debugging
2.Upgrade shielding/surge and protection functions
3Imported chips, imported raw materials
4.Applicable to all pole types (straight pole, Qubi pole, advertising gate, fence, etc.)
5.Strong anti-interference and environmental capabilities (no Fear of rain, snow, freezing and other weather)
6.Applicable to a wide range of scenarios (ramps, curves can be inclined
Operating Voltage | 10- 16V (typ. 12V/1A) |
Operating temperature | -40°C~85°C |
Average power consumption | < 2.5W |
Waterproof level | IP66 |
Communication Interface | RS485; Bluetooth |
Factory horizontal width | Default ±0.5 meters, can be customized within ±1.5 meters |
Factory longitudinal length | 1 -6m configurable, default 3m |
Online debugging | 485; Bluetooth communication debugging |
Online upgrade | 485;Bluetooth communication upgrade |
Appropriate types | Straight bars, fences, billboards, airborne gates |
ACB-T01 Single door Network Access Control board Control 1 door> Support 2pcs RFID access reader or 1pcs RFID access reader+1pcs Exit button> Free software to manage users> Real-time monitor
> Card type: EM Card> Metal case, anti-vandal> One Programming relay output > Multi-color LED Status Display > 1000 Users (100 Fingerprint + 890 Card + 10 Visitor)> Mini Size: L105 x W69 x H20 mm > Capacitive Fingerprint Sensor
> Wire diameter: 8mm> Door loop length: 400mm
> Wire diameter: 10mm> Inner Diameter: Support 2pcs 6mm cat6 wires
> Finger Capacity: 1000> User Capacity: 3000> LCD: 1.77 inches TFT colour screen> Work with 4pcs 1.5V “AA” alkaline battery> Optical sensorSupport USB to download attendance record(Support: Fingerprint+RFID+Pincode)
> Finger Capacity: 1000> User Capacity: 3000> LCD: 1.77 inches TFT colour screen> Work with 4pcs 1.5V “AA” alkaline battery> Optical sensorSupport USB to download attendance record(Support: Fingerprint+RFID+Pincode)
> Finger Capacity: 1000> User Capacity: 3000> LCD: 1.77 inches TFT colour screen> Work with 4pcs 1.5V “AA” alkaline battery> Semiconductor sensor(Support: Fingerprint+RFID+Pincode)Support USB to download attendance record
> Finger Capacity: 1000> User Capacity: 3000> LCD: 1.77 inches TFT colour screen> Work with 4pcs 1.5V “AA” alkaline battery> Semiconductor sensor(Support: Fingerprint+RFID+Pincode)Support USB to download attendance record
S4A appreciate any of your inquiries and sincerelyhope to enjoy a fruitful long-term business relationship with youto share in the mutual benefits, If you have any questions, please feel free to contact us.
